Technical Specifications & Chassis Compatibility
-
Chassis Compatibility: Suitable for Iveco Eurocargo ML75E, ML100E, ML120E, ML150E, and ML180E (ML190) chassis variants.
-
Deck Dimensions: Widths from 2,100 mm to 2,500 mm and lengths from 5,000 mm to 8,300 mm (custom-built based on chassis wheelbase).
-
Deck Flooring: Heavy-duty chequered steel plate or ultra-durable Hardox steel plate for high impact and abrasion resistance.
-
Hydraulic Winch Assembly: 5,000 kg – 8,000 kg capacity KMS hydraulic winch with a 24 m – 30 m steel wire rope, mounted on a lateral sliding winch frame (left/right adjustment).
-
Rear Stabilizers: Heavy-duty dual-acting rear hydraulic stabilizer legs to prevent chassis lifting and frame flex during deck extension.
-
Control Systems: Proportional wireless remote control paired with an auxiliary side-mounted manual hydraulic control lever panel.
-
Surface Coating: Full shot-blasting followed by 2 coats of anti-corrosive epoxy primer and a protective acrylic topcoat matched to fleet colors (optional hot-dip galvanization).
